OGB-2-10 OGB-3-7
——
6-10L automatic blow molding machine
Features：
1.The machine adopts human-computer interface to controlthe whole working procedures, auto-loading, auto blowing, auto dropping. Actioncylinders are all assembled with magnetic induction switches,.Connect with plc to control every step and test every cylinder. Next action willcontinue after the former step done, if former step is not finished, alorm automotically and do not work, plc displavs oroblem position.
2.Fast speed, accurate position, smooth action.
3.According to special demand, adopt cross double crank pressed clamping, with strong clamping force. Mould open stroke can be adjustable
according to the bottle size to save the time.
4.Farinfrared heaterlamps have strong penetrations , preforms are heated uniformly while rotating, PlC or elecronic pressure adlustor controls eachgroup of temperature separately.
5 .Particulgr pre-heater desion makes prefom close while heating, change space, shorten heating tunnel and reduce energy consumption accordingto the bottle size while blowing.
6.The dir supolv svstem consists of slight blow, high pressure blow, ow pressure actions, to supplv enouoh air for different products
7.Automatic lubrication oil device protects the machine well.
8. Production workmanshilp process is fuly automgtic to make bes auolty and pollution-free,it holds less invesiment, hioh eficiency, easy operctionsimple repair, safety etc
Main Data
Unit | OGB-2-10 | OGB-3-7 | |
Theoretical output | Pcs/hr | 1200 | 1800 |
| Max neck size | mm | 48 | 48 |
Volume | L | 10.0 | 6.0 |
Max. height | mm | 430 | 350 |
Max. diameter | mm | 220 | 190 |
Number of cavities | / | 2 | 3 |
Power | 220-380V 50-60HZ | 220-380V 50-60HZ | |
| Heating power | kw | 64 | 64 |
Total power | KW | 66 | 66 |
Main body dimension(LxWxH) | M | 3.7X1.9X2.2 | 4.5X1.9X2.2 |
| Main body weight | KG | 3500 | 4100 |
